Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 10 Vdc, 3-wire |
| Power Requirement | 14 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part | PT40-5000PSIG-2-5-2-14 |
| Size | 1/4″ |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 5000 psi gauge |
|---|---|
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 1/4 NPT male |
|---|---|
| Electrical Connection | DIN form A with 1/2 NPT female conduit |
