Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Requirement | 10 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part | PT40-300PSIG-2-2-8-8 |
| Size | 1/2″ |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 300 psi gauge |
|---|---|
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 1/2 NPT male |
|---|---|
| Electrical Connection | DIN form A |
